SEM512

SEM512

download files DOWNLOAD FILES

SEM510 512 SoilCompactor

Price Request

Optional Accessories

  • Soft CAB+AC
  • Compaction Meter
  • Cold Start (Air Inlet Heater, -20°c)
  • Rear Rain Wiper (Cab Only)
  • Radio (AM, FM) (Cab Only)
  • Pad Foot Shell Kit

Cab & Operation System

  • Canopy standard, Cabin + A/C optional
  • Big room, superior front, side and rear visibility
  • SEM512/510 is hydrostatic compactor. The operation system is very simple, it just has two control levers, onefor throttle control, another one is for forward/backward and brake control
  • A/C with interior cycle/out side fresh air cycle selection for better defog capability
  • Safety belt is standard

Key Applications

  • SEM510 and SEM512 SCOM are widely used in road work, sub-base, parking lots, site development, water and sewer trench work, hills and uneven terrain

Cooling System

  • Modular cooling package design
  • Up to 49°C ambient temperature cooling capacity

Hydraulic System

  • Improves efficiency by 20% vs. open center system
  • Reduces oil contamination, extends life of hydraulic system
  • Maintains higher system pressure with less energy loss
  • Allows for simpler hose routings
  • Requires smaller volume hydraulic tank, reduces maintenance cost

Cat &reg; Product Link<sup>TM</sup>

  • Cat ® Product Link™ will support your business, and accurately convey information of the equipment to relevant personnel in a timely and effective manner for your better equipment management.

Vibration System

  • Pod-style eccentric design
  • Dual amplitude and frequency with world class piston pump and motor

Drive Train

  • Hydrostatics drive with rear axle and drum drive
  • High performance coupler
  • Heavy duty rear axle with limited slip differential

Engine

  • Weichai WP4 engine with turbo charger and ATAAC
  • High fuel efficiency

Model

Model

SEM512

Engine Specification

Emission

China StageII

Std Rated Power-Gross

97.5kW

Rated Speed

2,200r/min

Composite Work Cycle Fuel Consumption (l/hour)

100% of XS122

Ambient Capability-HA Sea Level

49Deg C

Ambient Capability-Cold Weather

-10Deg C

Peak Torque/Speed - Gross

560/1,400-1,600N.m/rpm

Sound Level-Spectator

112dB(A)

Sound Level-Operator Position with Cab

86dB(A)

Compaction

100% of XS122

Operating Specifications

Operating weight with ROPS/FOPS

12380 +-3% kg

Weight at Drum w/Std Config

6,900±3%kg

Weight on Rear Axle

5,100kg

Static Linear Load

310N/cm

Max. Grade Ability w/o vibbration

45%

Articulated Angle

33±1°

Turning Radius Inside Drum Edge

5,990mm

Compaction Width

2,130mm

Ground Clearance

442mm

Travel Speed

Lo Range

0 to 5.5km/h

Hi Range

0 to 12km/h

Hydraulic Cycle Time

Full Turn Time

6±0.5s

Vibratory System

Freqency-Hi/Lo

33HZ/30HZ

Amplitude-Hi/Lo

1.80mm/0.90mm

Centrifugal Force-Hi/Lo

245kN/150kN

Dimensions

Machine Dimensions[L*W*H]

5,815*2,290*3130mm

Oscillation Angle

10±1°

Wheelbase

2,900mm

Tread Width

1,600mm

Drum Width

2,130mm

Drum Diameter

1,600mm

Tire Specs

Tire Specs

23.1-26 12PR12

Tire Pressure Setting

0.35Mpa

  • Std Rated Power-Gross: 97.5kW
  • Rated Speed: 2,200r/min
  • Turning Radius Inside Drum Edge: 5,990mm



  • Railway / Highway / Airport
  • Municipal Construction
  • Agriculture
  • Water Conservancy / Hydropower
  • Waste


  • High Reliability:
    Hydrostatic drive system with world class variable displacement piston pump and motors delivers leading in class reliability
  • High Productivity:
    Dual amplitude and frequency vibration system enable the operator to achieve better compaction result
  • High Efficiency:
    Up to 45% grade ability allows the machine to work efficiently on slop and uneven terrains
